Biodiesel Manufacturing Plant (Cap: 10,000 Ltr./Day)

BIODIESEL MANUFACTURING PLANT (CAP: 10,000 LTR./DAY)

[EIRI/EDPR/4786] J.C.: 3006XL

INTRODUCTION

Biodiesel refers to a non-petroleum-based diesel fuel consisting of short chain alkyl (methyl or ethyl) esters, made by Transesterfication of vegetable oil or animal fat (tallow), which can be used (alone, or blended with conventional petrodiesel) in unmodified diesel-engine vehicles. Biodiesel is distinguished from the straight vegetable oil (SVO) (sometimes referred to as "waste vegetable oil", "WVO", "used vegetable oil", "UVO", "pure plant oil", "PPO") used (alone, or blended) as fuels in some converted diesel vehicles. "Biodiesel" is standardized as mono-alkyl ester.

Biodiesel is a biofuel produced from various feedstocks’s including vegetable oils (such as oilseed, rapeseed and soya bean), animal fats or algae. Biodiesel can be blended with diesel for use in diesel engine vehicles. Biofuel – The term biofuel applies to any solid, liquid, or gaseous fuel produced from organic (once-living) matter. The word biofuel covers a wide range of products, some of which are commercially available today, and some of which are still in research and development. Biodiesel is a fuel made from plant oils that can be used in a conventional diesel engine.

Biodiesel is an environmentally safe, low polluting fuel for most diesel internal combustion and turbine engines. Can be mixed with petroleum diesel fuel and stored anywhere petroleum is. It is made from fresh or waste vegetable oils (triglycerides) that are a renewable energy source.

COST ESTIMATION

Plant Capacity            10,00 Ltr/Day

Land & Building (4000 sq.mt.)    Rs. 3.58 Cr

Plant & Machinery                    Rs. 3.30 Cr

Working Capital for 2 Months    Rs. 2.46 Cr

Total Capital Investment          Rs. 9.88 Cr

Rate of Return                          27%

Break Even Point                      51%
