Precipitated Calcium Carbonate/Burnt Lime

PRECIPITATED CALCIUM CARBONATE/BURNT LIME

[EIRI/EDPR/4766] J.C.: 2986XL

INTRODUCTION

Lime is a calcium-containing inorganic mineral in which oxides and hydroxides predominate. In the strict sense of the term, lime is calcium oxide or calcium hydroxide. It is also the name of the natural mineral (native lime) CaO which occurs as a product of coal seam fires and in altered limestone xenoliths in volcanic ejecta. The word lime originates with its earliest use as building mortar and has the sense of sticking or adhering.

These materials are still used in large quantities as building and engineering materials (including limestone products, cement, concrete, and mortar), as chemical feedstocks, and for sugar refining, among other uses. Lime industries and the use of many of the resulting products date from prehistoric times in both the Old World and the New World. Lime is used extensively for wastewater treatment with ferrous sulfate.

The rocks and minerals from which these materials are derived, typically limestone or chalk, are composed primarily of calcium carbonate. They may be cut, crushed, or pulverized and chemically altered. Burning (calcination) converts them into the highly caustic material quicklime (calcium oxide, CaO) and, through subsequent addition of water, into the less caustic (but still strongly alkaline) slaked lime or hydrated lime (calcium hydroxide, Ca(OH)2), the process of which is called slaking of lime. Lime kilns are the kilns used for lime burning and slaking.

In the lime industry, limestone is a general term for rocks that contain 80% or more of calcium or magnesium carbonates, including marble, chalk, oolite, and marl. Further classification is by composition as high calcium, argillaceous (clayey), silicious, conglomerate, magnesium, dolomite, and other limestones. Uncommon sources of lime include coral, sea shells, calcite and ankerite.

Limestone is extracted from quarries or mines. Part of the extracted stone, selected according to its chemical composition and optical granulometry, is calcinated at about 1,000°C (1,830°F) in different types of lime kilns to produce quicklime.

Before use, quicklime is hydrated, that is combined with water, called slaking, so hydrated lime is also known as slaked lime.

Dry slaking is when quicklime is slaked with just enough water to hydrate the quicklime, but remain as a powder and is referred to as hydrated lime. In wet slaking, a slight excess of water is added to hydrate the quicklime to a form referred to as lime putty.

Because lime has an adhesive property with bricks and stones, it is often used as binding material in masonry works. It is also used in whitewashing as wall coat to adhere the whitewash onto the wall.

COST ESTIMATION

Plant Capacity            50 MT/Day

Land & Building (4000 sq.mt.)    Rs. 1.91 Cr

Plant & Machinery                    Rs. 2.60 Cr

Working Capital for 2 Months    Rs. 2.95 Cr

Total Capital Investment          Rs. 7.76 Cr

Rate of Return                          31%

Break Even Point                      54%
